Standard-1 ( Rs 2555/- Per Sqft )
Design
- 2D Floor Plan
- 3D Floor Plan
- Center line Drawing
- Column marking Drawing
- Footing Drawing
- Structural Drawing
- Plumbing Drawing
- Electrical Drawing
- 3D Elevation Drawing
- Elevation details
- 3D Walkthrow
Structures
- Basement height: Upto 4 feet
- Steel: JSW / Amman TRY
- Aggregates: 20mm & 40mm
- Bricks: Cement Bricks / machine cut soil 9”(Rs.20/sft extra during rainy season due to increase in bricks price)
- Cement: Ultratec / Ramco
- M Sand: Brickwork
- Plastering : P sand
- Concrete: River Sand
- RCC Design Mix: M20
- Waterproofing: Tec mix
- Ceiling Height: 10 Feet
- Lintel Belt - Up to the Pillar
- Roof Reinforcement : 9" Beam with Reinforcement
- False ceilings : Living & Master B.Room
Kitchen
- Ceramic Wall Tiles 4 Feet Above Kitchen Slab Upto 35 Per Sq ft
- Main Sink Faucet Upto 1300 Rs
- Kitchen Sink: Stainless Steel Upto 3000 Rs
- Kitchen Granite Slab: 18 mm Thick Upto 135 Rs per Sq ft
Bathroom
- Wall Tiles ( 4' * 2' ) For 7 Feet Upto 45 Rs Per Sq ft
- Sanitary Ware & CP Fitting Upto Rs 10000.
- CPVC/PVC: Avon Plast
- Bathroom Accessories: EWC, Health Faucet, Wash Basin, 2 in 1 Wall Mixer, Overhead Shower
- All bathroom fittings are white color & basic model in Johnson
- PVC WaterProof Doors
Plumbing
- Bathroom – 1 wash basin with tap, 1 shower with wall mixer for hot & cold water, 1 floor mount western closet with health faucet.
- Dining – 1 wash basin with tap
- Kitchen – Double stainless steel sink with 1 taps. 1 RO point
- Service – 1 tap point & water outlet point for washing machine
Doors & Windows
- Main Door: Ready Made Teak Door With Teak Wood Frame of 5 Inch by 3 Inch, 38mm Thickness ,worth Rs.32,000 including fixtures
- Internal Door: Flush Door With Laminates Along With Sal Wood Frame of 4 Inch by 3 Inch
- Windows: Standard aluminium 2 Track sliding window with powder coating to the required colour / UPVC sliding windows (white color)
Door & Windows Sizes:
- Main Door – 3.5′(Width) X 7′(Height)
- Rooms – 3′(Width) X 7′ (Height)
- Bathroom & Balcony – 2.5′(Width) X 7′(Height)
- Window size – 4′(Width) X 4′(Height) (1 window per room)
Painting
Interior:
- 1 coat of white cement
- 2 coats of Asian/ Nippon putty
- 1 coat of Asian primer and 2 coats of Nippon Breeze paint for the walls (light colours)
- 1 coat of primer and 1 coat ( Recemmended ) of Asian tractor emulsion paint for the ceiling
Exterior:
- 1 coat of white cement
- 1 coat of Asian primer
- 2 coats of Asian ace emulsion paint (light colours)
Flooring
- Living & Dining Flooring( 4' * 2' ) : Tiles Upto 50 Rs Per Sqft
- Room & Kitchen Flooring ( 4' * 2' ): Tiles Upto 50 Rs Per Sqft
- Balcony & Open Area Flooring ( 2' * 2' / 1' * 1' Recemmended ) : Tiles Upto 45 Rs Per Sqft
- Staircase Flooring ( 1' * 1' ): Antiskid Tiles Upto 45 Rs Per Sqft
- Parking Tiles ( 1' * 1' ) : Anti-skid Tiles Upto 45 Rs Per Sqft
Electrical
- Wires – Finolex
- Switches – Anchor ( White / Grey ) / GM ( White )
Electrical Points:
- Living room - 1 switch box with switches for 1 fan, 2 lights and 1 five amps socket with switches near door and another switch box with 2 no 5 amp sockets 2 switches near sofa. 1 switch box with 2 five amps sockets and 2 switches along with cable point for TV connection
- Bedroom –1 AC point ( All Bed rooms ), 1 switch box with switches for 1 fan, 2 lights and 1 five amps socket with switch near door
- Bathroom - 1 switch box with 1 no light Switch & 1 Switch for Heater Point
- Dining-1 switch box with switches for 1 fan & 1 light
- Pooja- 1 switch box with 1 no switch for 1 light
- Kitchen- 1 switch box with switch for 1 lights, 1 fan &1 switch box with 15 amps socket for refrigerator. 1 switch box with one 15 amps socket & switch for mixie , 1no 5 amp socket for oven / grinder. 1 exhaust fan & Ro Point
- Parking -1 switch box with 3 switch for light, 1 switch for fan & 2 switches For Design Lights & others .
- Service- 1 switch box with 15 amps socket & switch for washing machine Extras
Lofts & Shelves
- 1 Loft in each bedroom, kitchen & pooja room on the shorter side of the wall , 1 Lofts in Kitchen
- 1 Shelf in each bedroom, kitchen & pooja room of maximum width 7 feet
Other Inclusives
- Overhead Tank: 1000 litres Aqua tec (3 Layer)
- MS Staircase Railing
- Parapet Wall 3 Feet High
- False ceiling in Hall & Master B.Room
- Roof weathering is included if the build-up area is more than 2000 sft.
